Waves & Information Technology

Two Ways to Encode a Message

Every time you send information through a wave, that information has to be encoded: turned into a pattern the wave can carry. There are two fundamentally different ways to do this: analog and digital. An analog signal encodes information as a smooth, continuously changing wave, exactly mirroring the original sound or image. A vinyl record works this way: tiny, continuously varying grooves are physically carved into the record to match the exact shape of the original sound wave, and a needle traces those grooves to recreate the music.

A digital signal instead breaks information down into discrete numbers, specifically a stream of 1s and 0s called bits. A digital music file doesn't store a continuous wave shape; it stores thousands of numerical snapshots of the wave taken every second, then rebuilds an extremely close approximation of the original sound when you hit play. It looks less "natural," but that difference turns out to be a superpower.

The quality of a digital recording depends heavily on how often those snapshots, called samples, are taken. Standard music CDs sample sound 44,100 times every single second: a rate chosen because it's just high enough to accurately capture every frequency the human ear can hear. Sample too infrequently, and the digital copy misses fast changes in the original wave, producing a choppy or distorted sound; that's part of why old, low-quality digital recordings from decades ago sometimes sound thin or robotic compared to a modern high-resolution digital file. It's a direct trade-off: more samples per second means a more faithful copy of the original wave, but also a larger file to store or transmit.

Why Digital Wins for Long-Distance Communication

Here's the problem with analog signals: every time they travel, get copied, or pass through interference (static, noise, scratches), tiny errors creep in and are impossible to separate from the real signal. That's because the whole signal is one smooth, continuous wave, so there's no way to tell an error from real data. That's why an old vinyl record picks up crackles and pops over time, and why a weak analog radio station gets fuzzy and staticky the farther you drive from the transmitter.

Digital signals solve this beautifully. Because the information is just a sequence of numbers (1s and 0s), a receiving device only has to decide between two options at each point: is this a 1 or a 0? Even if some noise sneaks in during transmission, it's usually easy to tell what the original bit was supposed to be, and many digital systems can detect and even correct errors automatically. That's why a streamed song sounds identical whether it just left the server or traveled halfway around the world, and why a digital photo can be copied a thousand times with zero loss in quality (something an analog photocopy could never do).

From Vibration to Light and Back Again

Modern communication technology is a nonstop relay race between mechanical and electromagnetic waves. When you talk into your phone, your voice creates a mechanical sound wave in the air. Your phone's microphone converts that mechanical wave into an electrical signal, digitizes it into 1s and 0s, and then converts it again into an electromagnetic wave (a radio wave) that can travel enormous distances at the speed of light without needing any medium at all.

Fiber optic cables take this even further, converting digital signals into pulses of light that race down hair-thin strands of glass, bouncing off the inner walls through total internal reflection for hundreds or even thousands of miles with almost no signal loss. Wifi routers do something similar, broadcasting your digitized data as radio waves through the air to every device in your house. At the other end, your friend's phone or laptop receives that electromagnetic wave, converts the digital data back into an electrical signal, and finally turns it back into a mechanical sound wave that vibrates a speaker, recreating your voice, your music, or your video call, often thousands of miles from where it started, all within a fraction of a second.

Real Technology, Real Impact

This analog-to-digital revolution touches nearly every piece of technology you use. CDs and streaming services replaced analog cassette tapes because digital audio doesn't degrade with each play or copy. Cell phones convert your voice into digital radio signals that can be compressed, encrypted, and transmitted efficiently across cell towers spanning entire countries. Wifi networks pack enormous amounts of digital information (video, photos, messages) into radio waves broadcast through your home. And fiber optic internet, which carries digital information as pulses of light, now forms the backbone of the global internet, moving unbelievable amounts of data between continents through cables laid across the ocean floor.

From talking drums to fiber optic cables, the core idea has never changed: waves carry both energy and information, and civilizations advance by getting better at encoding, transmitting, and decoding that information across greater distances, more reliably, and with less lost along the way.

How Much Can a Wave Carry? Bandwidth and Compression

Not every wave can carry the same amount of information at the same time, and that limit is called bandwidth: essentially, how much data a signal can transmit in a given amount of time, usually measured in bits per second. A narrow band of radio frequencies can only carry so many phone calls or so much video before it gets overloaded, which is exactly why old dial-up internet connections, squeezed through the narrow bandwidth of a telephone line, took minutes to load a single image that loads instantly today over a fiber optic or 5G connection carrying billions of bits every second.

Higher-frequency waves generally have more room to carry information, which is part of why engineers keep pushing communication technology toward higher frequencies, from AM radio, to FM radio, to wifi, to the newest 5G cell networks, with each jump unlocking dramatically more bandwidth. Fiber optic cables use light, an extremely high-frequency wave, which is a huge part of why they can carry such enormous amounts of internet data across entire oceans.

Engineers also rely on compression to squeeze more information into limited bandwidth. A streaming video service doesn't send every single detail of every frame; instead, clever algorithms remove information your eyes are unlikely to notice missing, like parts of an image that barely change from one frame to the next, shrinking the file dramatically without a noticeable drop in quality. That combination (higher-frequency waves carrying more bandwidth, plus compression squeezing data down further) is exactly why a two-hour movie can stream smoothly over a home internet connection instead of requiring an impossibly huge, uncompressed file.

How a Radio Wave Actually Carries a Song

A radio wave by itself is featureless: a smooth, repeating wave with nothing in it to hear. To carry a song, that plain wave has to be altered in a pattern that matches the sound, and there are two classic ways to do it. Both start with a steady wave called the carrier, at whatever frequency the station broadcasts on.

The first method changes the carrier's amplitude, making it taller and shorter in step with the music. That is AM, which stands for amplitude modulation, and modulation is just a technical word for altering the wave on purpose. The second method leaves the height alone and nudges the frequency up and down instead, squeezing and stretching the wave. That is FM, frequency modulation. The numbers on a radio dial are carrier frequencies: 101.5 on the FM dial means 101.5 megahertz, or 101.5 million wave cycles every second.

This difference explains something you may have noticed on a long drive at night. AM stations fade in and out and pick up crackle during a thunderstorm, while FM stations either sound clean or vanish entirely. Lightning and electrical equipment mostly add stray amplitude, which an AM receiver cannot tell apart from the signal, so the noise comes through as static. An FM receiver reads only the frequency changes and simply ignores amplitude wobble, so it shrugs off the same interference.

Notice that this is the analog-versus-digital idea from the start of the chapter showing up again in a different costume. AM and FM are both analog: the wave varies smoothly and any distortion picked up along the way rides along as part of the signal. A digital broadcast sends only ones and zeros, and a receiver only has to decide which of two values each piece is, so small distortions get rounded away entirely. The trend from AM to FM to digital is really one long effort to keep noise from reaching your ears.
